Shale shaker is the first stage solids control equipment. It is used to separate solids from mud coming from well head. Then the clean mud treated by desander, desilter or centrifuge and back to the well head for drilling.

GN Solids Control can make whole range of shale shaker model

1) Mini shale shaker, 2 – panel for small mud systems:Model GNZS752 shale shaker, GNZS852 shale shaker

2) Linear motion 3-panel shale shaker: GNZS703 shale shaker

3) High G shale shaker: GNZS853 high G shaker

4) Double deck shale shaker: GNZS703D

GN solids control can design and manufacture all type of wire mesh shale shaker screen for oil and gas field.

GN Solids Control can make different type replacement shale shaker screen for GN brand shaker , for Derrick shaker, for NOV shaker and for MI Swaco shaker, as well as other world famous shaker brand.

Hook strip shale shaker screen

For Derrick 48-30 shaker screen, Derrick FLC500 shaker screen, Scomi shale shaker,etc…

Steel frame shale shaker screen

For Brandt King Cobra shale shaker screen, Swaco Mongoose shaker screen.GNZS703 shale shaker, GNZS853 shale shaker, VSM300 shale shaker

Composite material shale shaker

1) VSM300 shale shaker screen

2) Swaco mongoose shale shaker screen

3) GNZS703 shale shaker screen

Waterwell drilling rig, it is usually dig small height hole may around 50~300m or more. Mostly they do not match mud system,even they have, only smaller mud system request.

But as the water well drilling rig need to be moved very frequently, for easy rig up and rig down, mud system and every solids control equipment should be very convenient to move.

GN have designed many fast move small mud system for water well drilling. GN make mobile fast move system from mud recycling to mud mixing to max. compact design. So the total system can be move no need to disassembly anything.

Character of high G shaker

High G shaker is a kind of shale shaker utilize high G force used in waste management field. It is adapt high G force from 7.5 to 8.0 G.

Upstream equipment of drilling waste of high G shaker

A set of screw conveyor system collect drilling solids separated from shale shaker, desander, desilter and centrifuge,and then transfer and dump to high G shaker for separation.

During this process, clean mud falls into slurry tank under high G shaker, drilling cuttings dump to cutting box and move away by track for further treatment.

Down stream equipment drilling waste of high G shaker

Clean fluids from high G shaker transferred to a waste management high speed centrifuge, fine solids above 2~5 micros will be moved away after centrifuge process.

Swaco mongoose shale shaker is a dual motion shale shaker, adapt composite shale shaker screen.

What is composite shale shaker screen (Swaco Mongoose, GNZS703, ETC):

It is a kind of shaker screen with special mateiral and processing tochnology, it usually has matel inside and rubber outside.

Advantages of composite shale shaker screen:

Under the same working situation, composite screen have over double lifetime compaired with same model steel screen.

GNZS703 shale shaker is a hot sale model as the replacement of Mongoose shale shaker, they both adapt composite shaker screen.

You can visit GN website for more information of GNZS703 shale shaker and its high quality replacement shaker screen.
